1,400WPeak Motor -
28 MPHTop Speed -
55 MilesMax Range -
20x4"Fat Tires -
692WhBattery Capacity -
400 lbsMax Load
Ranger S 750W + Jackery 1000 Plus
Powerful folding ebike with fat tires for versatile usages
-
1,400WPeak Motor
-
28 MPHTop Speed
-
55 MilesMax Range
-
20x4"Fat Tires
-
692WhBattery Capacity
-
400 lbsMax Load
In stock! Free, Fast Shipping Within 2 business days!
Ranger S: A folding electric bike equipped with a powerful 750W motor. It offers a remarkable range of up to 55 miles on a single charge, allowing riders to explore their surroundings with ease and convenience.
Jackery 1000 Plus: Your all-in-one portable power station for powering your life. With a 1264Wh capacity and a 2000W output, it supports 99% of your devices, ensuring you stay powered up wherever you are.
Shipping & Warranty
We guarantee fast and free shipping within 2 business days and offer a 2-year warranty for each ebike.
Learn More
Compare Models
Hesitate to choose a suitable ebike? Check the comparison chart to make an informed decision.
Contact Us
Feel free to contact us if you have any questions. We are always here to help you 24/7!
Discover Ranger S
The Ranger S e-bike is a folding electric bike equipped with a powerful 750W motor. It offers a remarkable range of up to 55 miles on a single charge, allowing riders to explore their surroundings with ease and convenience.
Join Force to Your Out Door Adventure
Jackery 1000 Plus
The Jackery Explorer 1000 Plus is your all-in-one portable power station for powering your life. With a 1264Wh capacity and a 2000W output, it supports 99% of your devices, ensuring you stay powered up wherever you are.
Ranger S Spec&Size
Frameset
Frame
Aluminum Alloy;
removable lithium-ion battery;
rear rack and fenders included;
front & rear mount hydraulic disc;
kickstand mount
Fork
Hydraulic front suspension fork
Wheels
Hub rear
750W Version: 80Nm torque,
750W (sustained), 1400W (peak)
1000W Version: 100Nm torque,
1000W (sustained), 1800W (peak)
Tire Construction
Unibody, puncture protection, 20"x4.0"-max tire size without fenders
E-system & Drivetrain
Battery
48V, 14.4Ah (692Wh)
Fast Charger
48V 4A
Display Type
Smart LCD Display
Rear Derailleur
Shimano 7 speed
Accessories
Rear Rack
Max Load: 120 lbs
Light
LED, headlight and taillight
Kickstand
Alloy
Weight & Dimensions
Weight
32.66 kg / 72 lbs
Weight limit
Maximum total weight limit (combined weight of rider and cargo) of 400 pounds (181kg).
Folded Dimensions
40*20*31 inch
Unfolded Dimensions
70*24.4*50 inch
What's In The Box
Ranger S
Charger
User Manual
Toolkit Box
Keys
Jackery Explorer 1000 Plus Spec&Size
Specs
Battery
Capacity:
1264.64Wh
Cell Chemistry:
LiFePO4
Cycle life:
4000 cycles to 70%+ capacity
Management System:
BMS, Over Voltage Protection, Short Circuit Protection
Dimensions
Weight:
32lbs (14.5kg)
Height:
11.14in (28.3cm)
Width:
10.24in (26cm)
Length:
14in (35.6cm)
Charging Time(0-100%)
AC Adapter:
1.7 Hours
Car Adapter(12V):
7 Hours
Solar Panel:
3 Hours
Gerneral
Warranty:
3+2 Years
Operating Usage Temperature:
14-113℉ (-10~45℃)
Ports
AC Output(x3):
120V~60Hz, 2000W (4000W Peak)
USB-A Output(x2):
18W Max, 5-5V⎓3A
USB-C Output(x2):
100W Max, (5V, 9V, 12V, 15V, 20V up to 5A)
Car Port(x1):
12V⎓10A
AC Input:
100V-120V, 60Hz, 15A Max
Charge mode AC input:
100V-120V, 60Hz, 15A Max
Bypass mode AC input/output:
100V-120V, 60Hz, 15A Max
DC Input:
12-60V, 8A ⎓ 11A Max, Double to 22A/800W Max
Solar Panel Combination
Solar Saga 100:
Up to 6 Pcs (with solar connector)
Solar Saga 200:
Up to 4 Pcs (with solar connector)
What's in The Box
1. Jackery Explorer 1000 Plus
2. Car Charge Cable
3. AC Charge Cable
4. DC7909 to DC8020 Adaptor x2
FAQs
How will my order be shipped and what is the estimated delivery time?
After placing an order, products will be shipped separately by Jackery's official website and Heybike’s official website with an estimated delivery time of 3–5 business days.
What's the warranty for Heybike and Jackery's products?
Heybike offers a 2-year warranty for each ebike. Jackery offers a 3+2 year warranty for Explorer 600 Plus and Explorer 1000 Plus. Each product is subject to the warranty policy of its respective official store. Please refer to the related official store for its detailed warranty policy.
Can the Jackery 1000 Plus portable power station charge the Ranger S?
Yes, the Jackery 1000 plus included in our co-branded bundle can charge the Ranger S. This ensures you have a reliable power source for extended rides and outdoor adventures.
What Types of Terrain Can Ranger S Handle?
Ranger S ebikes are designed for off-road use on rugged, unpaved surfaces with their wide and fat tires. These surfaces include dirt trails, gravel roads, grass, sand, and light snow. They can handle rougher terrains better than bikes with narrow road tires, but may still struggle on very technical mountain trails. Ranger S is also suitable for all-season use.
Can I Ride Ranger S in The Rain?
Though Heybike e-bikes are designed to handle wet conditions, please keep in mind that riding in heavy rain may affect battery life and reduce traction, so exercise caution and avoid riding in the rain as much as possible.As for the waterproof level, the whole bike meets IP54 standards; the motor, battery, and display meet IP64 standards.
Are Ranger S E-Bikes Suitable for All Ages and Fitness Levels?
Heybike e-bikes are generally suitable for a wide range of ages (above 16 years old) and fitness levels, as the electric motor provides adjustable assistance to accommodate different riding abilities. Besides, please note the max load for Ranger S is 400 lbs, and please consult with a healthcare professional if you have any health concerns before riding.
Can I transport Ranger S in a car trunk?
Ranger S can be folded and stored in a car trunk. Its folded dimensions are 40*20*31 inch, and its unfolded dimensions are 70*24.4*50 inch.
Does my height/weight suit the Ranger S?
The recommended rider height for Ranger S is 4'11" ~ 6'3"; The total payload capacity of Ranger S is 400 lbs (not including the bike weight).
Is my Ranger S pre-assembled?
The Ranger S is partially assembled. You have to install some parts by yourself, such as the front wheel, handlebar, saddle, pedals, and fender. You can download the Ranger S user manual or look at the assembly video for help.
